| No. | Machine name | QTY | Remarks |
| 1 | Mill Roll Stand | 7 sets | The RS - 1500 type, Base paper lifting, clamping loosening, left
shift, right shift are hydraulic control, two brakes, expand chuck. The maximum paper width is 1850mm, the maximum paper diameter
1500mm Hydraulic valve made in Tianyuan . |
| 2 | Rail and Tracks | 14 sets | 6m railing with pulley 16# channel steel |
| 3 | Pre-heater | 3 sets | MH-600,900,1000,1100T .￠600mm,900mm,1000mm,1100mm, electric adjust
wrapping angle Wall Thickness 18 |
| 4 | Single facer | 3 sets | Single facer(SF280S/320S/360S or HF series), corrugated roller
￠(280,320,360,380,408)mm. Corrugated Rollers 48CrMo alloy steel Corrugated Rolls tungsten carbide, Origin : RMM Applicator glue roller,doctor glue roller Origin:Jiangsu Haili Digital show glue quantity.glue part can remove Electric adjusts glue area. Gimbal drive Bearings:(mainly)NSK Japan; Delta frequency changer |
| 5 | Pre-conditioner | 3 sets | MH-600,900,1000,1100T .￠600mm,900mm,1000mm,1100mm, electric adjust
wrapping angle Wall Thickness 18 |
| 6 | Three Layer Bridge Conveyor | 1 set | BS-T Adsorption, frequency leading paper Three layers |
| 7 | Four Pre-heater | 1 set | MH-600,900,1000,1100T .￠600mm,900mm,1000mm,1100mm900mm, electric
adjust wrapping angle Wall Thickness 18 |
| 8 | Triplex Gluing Machine | 1 set | GA-288D. Gluing roll diameter 288mm Origin:Jiangsu Haili Dividing glue roller diameter:120mm Origin:Jiangsu Haili Figure show gluing details, main bearing adopt NSK brand,press
rolls type,or system for variable wrap on glue applicator
roll,modular system for easy clean of glue rolls PLC control |
| 9 | Double Facer | 1 set | DF-745. Heating plants: 600mm×20,hydraulic lift down,big worm box,converter
motor . With 12pcs press plate Wall plate casting,main drive with rubber |
| 10 | Main Driven | 1 set | DF-745 Diameter 745mm Rubber roller Independent reducer box, gimbal driving. |
| 11 | NC slitter | 1 | Change order 5-8second,zero press line, Suction scrap device |
| 12 | Trim suction system | 1 | Waste paper suction system |
| 13 | NC cutter | 1 | SNC-180N, Paper length is 9999mm. The computer can store multiple
orders, the man-machine interface is separated, the display shows
production information, and the computer controls the automatic
change list without stopping the machine. Paper cutting accuracy +
1mm. Cutter shaft of 228mm spiral knife in Taiwan |
| 14 | Paper holder | 1 | Pneumatic |
| 15 | Automatic gantry stacker | 1 | CF-180, the upper pile length: 3500 mm; stacking height: 250 mm,
lower stacking length: 3000 mm |
| 16 | Glue making system | 1 set | GF-T.Main Glue Making System. Main pot 1 set, carrier pot 1 set, and storage pot 1set Glue station pump, single facer glue pump and gluing machine glue
pump. Circle supply glue, pipeline provided by customer |
| 17 | Pneumatic system | 1 set | GF-T Pneumatic System. Include0.9m3storge tank1. Pump and pipeline provided by customer |
| 18 | Electric system | 1 set | EF-T Electric control system including wires from switch board to main motor. Domestic famous brand :Chint etc |
| 19 | Steam system | 1 set | SP-S Steam system Shanghai drain water valve ,main wires by buyer |
